Track bar answer
There are many types of track bar configurations in use and different mounting methods. I will be describing the most common configuration used for oval track racing.

The track bar is also known as the panhard bar. The purpose of this is to locate the rear end along the centerline of the chassis. It is attached to the rear end housing on one end usually near the center of the rear axle at the differential ( sometimes on the axle housing itself depending on the type of car: short track, intermediate, or superspeedway) and is attached to a mounting bracket on the chassis just inside of a rear wheel (most often the right rear). We will assume a single panhard bar mounted to the RIGHT rear for this example.

The mounting bracket used to have a series of vertical holes drilled in it so that the bar could be unbolted and moved up or down as required then rebolted. The mounting bracket is still this way in many racing series. The Cup cars now have the bracket fabricated such that the bar can be adjusted up or down using a long through-bolt similar to the jacking bolt used to adjust wedge. They use a wrench through the rear window as well.

The length of the track bar (or panhard bar) is also adjustable. Each end of the bar has a threaded hiem joint that can be screwed in or out to either lengthen or shorten the bar. Teams have different approaches to the initial set-up of the track bar. One common approach is to set the length of the track bar such that the the rear end is centered in the chassis when the bar is in the middle of the adjustable chassis bracket. The bracket is often mounted to the chassis in such a way that the track bar is perfectly horizontal (level) at the lowest setting. Therefore, the distance between the center of the rear end and the chassis mount would be shortened as the bar is moved upward and the distance would be lengthened as the bar is moved downward.

Adjusting the track bar end UPWARD moves the rear end (and therefore both rear tires - because they are connected by a common axle housing) TO THE RIGHT.

Adjusting it DOWNWARD moves the rear end (and both rear tires) TO THE LEFT.

So whats the point you ask?

Lets start by understanding the term track as it relates to the car. When both the front and rear tires are lined up perfectly parallel (down the same centerline from front to rear) it is said that the rear wheels are "following the front wheels". This is called "tracking straight". When the rear wheels are shifted to the right or left of the front wheels it is said that the rear wheels are "dog tracking" (based on a dogs tendency to shift its front and rear legs in opposite directions when changing directions on the run).

I am not fond of the term track bar because it is misleading. Many folks become confused when talking about the track bar because of the dog tracking example. Often people think that shifting the rear end to the right or left will make the car turn to one side or the other when rolling forward in a straight line. This is not the case. When the rear end is positioned squarely in the chassis (trailing arms are the same length -more on these another time - and the rear end is perpendicular to the centerline) the car will still roll straight despite the rear axle (and both rear tires) being shifted to the right or left.

Therefore, I will refer to the "track bar" using its proper name panhard bar during the rest of this explanation. Panhard (old time automotive inventor) invented this diagonal link to laterally position the rear axle in his cars.

Now that we understand that adjusting the panhard bar shifts the rear end right or left it is easy to imagine that this will have an effect on the cars handling. We need to understand one more concept first. This is the concept of roll center. Roll center is simply the point at which the sprung weight of the car rolls from side to side. This is also one of the most misunderstood concepts in chassis set-up. I am not going to go into the full physics/engineering version here. It is a rather complicated concept that includes lateral forces, rotational forces, center of gravity location, raising and lowering of roll centers and effective roll couple, etc...

Soooo... I am going to explain it in a way that you can imagine for practical application. Pretend that a car has had its tires removed and is only supported by two jackstands. One in the center of the front of the car and one in the center of the rear of the car. These two jack stands would represent the roll center of the car. It would be at this point that the weight would balance. The car could easily be rocked from side to side (weight would roll from one side to the other). Lets concentrate on the rear of the car. If the jackstand were moved to the right then more of the cars weight would be placed on the left side of the jackstand. If the jackstand were moved to the left then more of the cars weight would be shifted to the right side of the jackstand.

O.K. now lets put the tires back on.
We remember that a car in a turn transfers weight from the inside of the car to the outside of the car due to centrifugal force. On an oval track that means more weight moves from the left side to the right side in a turn. Thus, when the rear end is moved to the right more weight is moved to the left of the centerline. This allows more weight to transfer during cornering (more body roll). The opposite is true if the rear end is shifted to the left more then weight is moved to the right of the centerline and less weight is available for weight transfer to the right side (less body roll) during cornering.

In the swaybar discussion we determined that the more the body rolls the more the right side spring is compressed and the more the left side spring expands. The more the left side expands the less force is placed on the tire, the smaller the contact patch, the less traction is available and the looser the car becomes.

Conversely, the lower the body roll the more traction is maintained by both tires and the tighter the car becomes.

The crew chief sees it this way:

Raising the track bar makes the car looser (oversteer)

Lowering the track bar makes the car tighter (understeer)

Enough for now - enjoy.

ZNAKOMI
Administrator
Posts: 1579
(8/14/02 5:11:18 pm)
Re: Track bar answer
That's really interesting, moving it up puts a greater percentage of weight on the left side, but in a corner you'll actually end up with less on the left side because that greater percentage is now available to be thrown right. Who woulda thought!

Hey gofour, maybe you could bundle these posts together and sell 'em to nascar.com. I learned more in a few posts than I've learned in 10+ years of watching it on TV. I think a lot of fans would love to read this stuff. You explain these things extremely well.

Thanks for taking the time!
